Gantry side palletizer

Product Description:

Gantry push palletizer is one of the low palletizer, is a high degree of automation structure simple palletizer. Gantry side palletizing machine products will be organized according to a predetermined way, and then the whole product layer on the tray on the code. Usually as a follow-up equipment of the packaging line, improve the production capacity and transport capacity.

Features:

★ Touch screen operation to achieve man-machine dialogue, can show the production speed, cause of the malfunction and location, high degree of automation.

★ Adopt PLC programmable to sort cartons or buckets stacking layer, pallet supply and discharge can be programmed into the program control.

★ Mitsubishi PLC and Wei Lun brand touch screen or other imported brands, electrical components comply with international standards, reliable performance, interchangeability, durability and strong.

★ Japan's SMC and Taiwan Yade off production of pneumatic components and cylinders, quality, reliable performance.

★ safety door, hood equipped with electrical induction device, when the cover door is opened, the machine stops working, personnel can be protected.

★ stack adjustment easy, simple, can be carried out on the touch screen.

Stable stacking, high efficiency, can greatly save manpower.

★ Carton supply system uses brake motor control, to ensure that the pre-set position to deliver cartons or barrels.

★ large capacity pallets, can accommodate 5-8 empty pallets, pallet can be automatically supplied.

★ low noise in line with China's international standards for noise below 75db.

★ Do not need to change the stacking parts to complete several stacking methods.

★ servo motor Panasonic or Mitsubishi brand, motor reducer Taiwan Sheng state motor brand.

product material:

Rack: SS41 (A3 steel spray paint)

Shaft: S45C bearing steel

Roller: double-ended bearing roller (galvanized)

Hood: SS41 (A3 steel spray paint)

Guide plate: SS41 (A3 steel spray paint)

Public consumption:

Power: AC, 3-phase, 380V, 6KW 50HZ

Air consumption: 500NL / MIN (air usage: 5-6kg / cm2)
